Frame Screw Smart PGB 7.5×162 mm cylindrical 100 pcs + bit TORX T30

Frame Screw SMART CHD T30 7.5 × 162 mm, cylindrical head, zinc-plated (code SM0WSC0010751623)

Professional frame screw from the SMART brand, designed for mounting window and door frames directly into wood, concrete, or brick. Thanks to its self-drilling tip and optimal thread geometry, it ensures quick, secure, and aesthetically pleasing fastening without the use of additional expansion plugs.

Product Advantages:

• No plugs required – self-drilling thread eliminates the need for expansions, speeding up installation work.
• Fast work – small pilot drill diameter Ø 6 mm allows for easy screw insertion.
• Stress-free installation – “stress-free” installation guarantees uniform insertion and stable profile placement.
• HiLo thread – dual-level thread optimizes grip in the material, enhancing holding strength and preventing wood splitting.
• Torx T30 drive – excellent torque transmission, reduction of "cam-out" effect, and longer bit lifespan.
• Corrosion protection – durable galvanic coating (Zp) protects against corrosion even in challenging conditions.

Applications:

• fastening and leveling window and door frames in wooden, concrete, and masonry structures,
• installation of sub-sill profiles and bases in insulation systems,
• fixing aluminum-PVC elements and lightweight constructions,
• wherever quick, secure, and aesthetically pleasing frame fastening is needed.

Technical Data:

• Product Code: SM0WSC0010751623
• Brand: SMART
• Material: hardened steel, galvanic zinc coating
• Dimensions: Ø 7.5 mm × 162 mm
• Pilot drill diameter (d₀): 6 mm
• Drive: Torx T30
• Head Type: cylindrical
• Package Quantity: 100 pcs
• Country of Production: Poland (PGB-Polska)
