Frame Screw Smart PGB 7.5×152 mm Conical Head 100 pcs + TORX T30 Bit

SMART Frame Screw CHD T30 7.5 × 152 mm, conical head, zinc-plated (code SM0WSF0010751523)

Professional frame screw by SMART designed for mounting window and door frames directly into wood, concrete, or brick. Thanks to the self-drilling tip and optimal thread geometry, it ensures fast, secure, and aesthetic fastening without the need for additional expansion plugs.

Product advantages:

• Plug-free installation – self-drilling thread eliminates the need for expansions, speeding up installation work.
• Fast work – small pilot drill diameter Ø 6 mm allows for efficient screw placement.
• Stress-free installation – "stress-free" installation ensures even insertion and stable profile anchoring.
• HiLo thread – dual-level thread optimizes grip in the material, increasing holding strength and preventing wood splitting.
• Torx T30 drive – excellent torque transmission, reduced "cam-out" effect, and longer bit lifespan.
• Corrosion protection – durable galvanic coating (Zp) protects against corrosion even in harsh conditions.

Applications:

• fastening and leveling window and door frames in wooden, concrete, and masonry structures,
• installation of sub-sill profiles and bases in insulation systems,
• embedding aluminum-PVC elements and lightweight structures,
• wherever quick, secure, and aesthetic frame fastening is needed.

Technical data:

• Product code: SM0WSF0010751523
• Brand: SMART
• Material: hardened steel, galvanic zinc coating
• Dimensions: Ø 7.5 mm × 152 mm
• Pilot drill diameter (d₀): 6 mm
• Drive: Torx T30
• Head type: conical
• Package quantity: 100 pcs
• Country of production: Poland (PGB-Polska)
