Smart PGB Frame Screw 7.5×122 mm Cylindrical 100 pcs + TORX T30 Bit

SMART CHD T30 Frame Screw 7.5 × 122 mm, Cylindrical Head, Zinc-Plated (Code SM0WSC0010751223)

Professional frame screw by SMART, designed for mounting window and door frames directly into wood, concrete, or brick. With its self-drilling tip and optimal thread geometry, it ensures quick, secure, and aesthetic fastening without the need for additional expansion plugs.

Product Advantages:

• Plug-free installation – the self-drilling thread eliminates the need for anchors, speeding up installation work.
• Quick work – the small pilot drill diameter Ø 6 mm allows for easy screw insertion.
• Stress-free installation – guarantees uniform insertion and stable profile seating.
• HiLo Thread – dual-level thread optimizes grip in the material, increasing holding strength and preventing wood splitting.
• Torx T30 Drive – excellent torque transmission, reduced "cam-out" effect, and extended bit lifespan.
• Corrosion protection – durable galvanic coating (Zp) protects against corrosion even in harsh conditions.

Applications:

• fastening and leveling window and door frames in wooden, concrete, and masonry structures,
• installing sub-sill profiles and bases in insulation systems,
• mounting aluminum-PVC elements and lightweight structures,
• wherever quick, secure, and aesthetic frame fastening is needed.

Technical Data:

• Product Code: SM0WSC0010751223
• Brand: SMART
• Material: Hardened steel, zinc-plated galvanic coating
• Dimensions: Ø 7.5 mm × 122 mm
• Pilot Drill Diameter (d₀): 6 mm
• Drive: Torx T30
• Head Type: Cylindrical
• Quantity in Package: 100 pcs
• Country of Manufacture: Poland (PGB-Polska)
